Wrapping machine for you bigger products
Stretch film tensioning with ELECTROMAGNETIC BRAKE
Pallet height detected by photocell
Anti-fall device on the film carrier
Film carrier SPEED regulation
Separate programming of high and low reinforcement wraps
Electronic control panel with 10 password protected wrapping cycles
Arm rotation regulated by inverter from 4 to 15 rpm
Wrapping height on request
Standard wrapping height
Up to 3 years warranty
Pallet dimensions up to 3000×1250 mm
Arm stop position controlled by sensor
WATCH THE PICTURES
DESIGNED AND PRODUCED BY EFFE3TI
The XL version of the Rotax S3200 semi-automatic wrapping machine is specifically designed to effectively wrap the most bulky products, while offering the high productivity typical of wrapping machines with rotating arm.
Pallet wrapping machine with electromagnetic brake for tensioning the stretch film
- Designed to wrap palletised loads with unlimited load capacity.
- The machine has 10 password protected programs.
- Standard machine pallet height h = 2100mm detected by photocell; on request special heights up to 3000 mm
- The rotation speed of the arm is regulated by an inverter (adjustable rotation from 4 to 15 rpm)
- Arm stop position controlled by sensor
- Customisable speed of the film carrier regulated by inverter
- Anti-fall system on the film carrier
